SunBar 2000FC

LIGHT SOURCE

• Source: 1.024x1W RGBW LEDs
• CCT: W: 6.500
• Luminous flux: Strobe without lens (peak) 126000 lm; Static ON without lens 25774; Strobe with lens (peak) 46200; Static ON with lens 19183
• Lux: (115°) 1'005 lx - (37°) 3'457lx @3 m full
• Lux: (115°) 362 lx - (37°) 1'244lx @5 m full
• Source life expectancy: > 30.000 h

OPTICS

• Beam angle: without lens 115°, with lens 37°
• Field angle: without lens 155°, with lens 84°
• Other: Mountable 40° lens reflector plate (included)

COLOUR SYSTEM

• Colour mixing: RGBW / FC
• White presets: 2.800 K -10.000K
• Colour wheel: virtual colour wheel with macros

DYNAMIC EFFECTS

• Rotating gobos: dynamic patterns with speed and rotation control
• Pixel patterns: pre-programmed dynamic and static patterns
• FX generator: adjustable foreground/background colour, index, speed, direction
• Static mode: selection of static colour
• Manual mode: manual adjustment of colour
• Auto mode: built-in programs with execution speed adjustment
• Special features: Multi-layer pixel FX control

BODY

• Hardware on-board: sockets for quick-Lock Omega bracket (clamp not included)
• Body: sturdy die-cast aluminium body
• Body colour: black

CONTROL

• Protocols: DMX512, RDM, Art-Net, Kling-Net
• DMX channels: from 4 ch to 87channel
• Pixel control: 1 / 2 / 4 / 8 / 16 individually select and control sections
• RDM: RDM for remote monitoring and settings
• Display: black TFT touch display
• Firmware upgrade: via DMX with UPBOXPRO/UPBOX1 (USB-DMX interface not included)

ELECTRONICS

• Dimmer: linear 0 ~ 100% electronic dimmer
• Dimmer curves: 4 selectable dimming modes available
• Strobe / shutter: 1 - 30 Hz, electronic
• Operating temperature: -10° ~ +45° Ta
• Selectable PWM: 600 ~ 25.000 Hz

ELECTRICAL

• Mains power supply: 100-240V - 50/60Hz
• Max power consumption: strobe: 987 W - static: 610W
• Max power consumption (at 120V): strobe: 1.065 W - static: 630W
• Output (at 230V): 3 units on a single power line
• Output (at 120V): 1 units on a single power line
• Power factor: 0,98

PHYSICAL

• IP rating: 20
• Cooling: active, silent operation
• Suspension and fixing: hanging bracket for floor positioning with "Quick-Lock" system
• Signal connection: Amphenol XLR 5p IN/OUT connectors
• Data connection: Art-Net RJ45 IN/OUT
• Power connection: Seetronic powerCON waterproof IN/OUT connectors
• Dimensions (WxHxD): 1000x75x231mm / 39.37''x2.95''x9.09''
• Dimensions with PO system (WxHxD): mm / ''
• Weight: 9,5kg / 20.94lbs

CERTIFICATIONS / APPROVALS

• Certifications / Approvals: CE, UKCA, RCM

BOX CONTENT

• 1 x SUNBAR2000FC
• 1 x 1,5 meters power cable (BARE END - SEETRONIC IP65 power connector)
• User Manual
