Pin Spot

LIGHT SOURCE

• Source: 13W high-power white LED
• CCT: (TU) 2.800 K - (DY) 6.100
• Luminous flux: (TU) 574 lm - (DY) 816
• Lux: (TU) 4'474 lx - (DY) 6'608lx @3 m
• CRI: (TU) 90 - (DY) 80
• Source life expectancy: > 30.000 h

OPTICS

• Beam angle: 6°
• Field angle: 11°

DYNAMIC EFFECTS

• Manual mode: manual adjustment of dimmer

BODY

• Body: sturdy die-cast aluminium body
• Body colour: black

ELECTRONICS

• Dimmer: linear 0 ~ 100%, manual knob dimmer
• Operating temperature: -10° ~ +45° Ta

ELECTRICAL

• Mains power supply: 100-240V - 50/60Hz
• Max power consumption: 18,9W
• Max power consumption (at 120V): 19,6W

PHYSICAL

• IP rating: 30
• Cooling: passive cooling and fan-free
• Suspension and fixing: bracket for hanging and positioning
• Power connection: moulded IP power IN connector
• Dimensions (WxHxD): 209x167x238mm / 8.23''x6.57''x9.37''
• Weight: 1,8kg / 3.97lbs

CERTIFICATIONS / APPROVALS

• Certifications / Approvals: CE, UKCA, RCM

BOX CONTENT

• 1 x PINSPOT
• User Manual
