GammaPix 48T1X2WF

Name: GammaPix 48T1X2WF
Brand: Prolights
SKU: GAMMAX48T1X2WF
Price: 1834.8 EUR
Availability: InStock

Outdoor rental 4,8 mm LED screen, 50x100cm tile, black frame & white face LEDs

1,834.80€

(Including VAT 20%)

SKU: GAMMAX48T1X2WF

Category: Video, Outdoor LED Screens

Tag: prolights, audio visual store, video, outdoor led screens

GammaPix 48T is a rental LED screen for outdoor use with a 4,8 mm pixel pitch, designed to meet requirements for touring, events and install applications. This series is available in both 50x50cm and 50x100cm tiles, mechanically compatible in order to assemble a large surface of screen in a shorter time.
The mechanical design of the tiles has been conceived to allow fast single person installation with automatic lock design and extra safety & handling features such as scratch protection of the lamp face, flip corner shield and bottom protection.

GammaPix 48T tiles have on board curve mechanics allowing both concave and convex precise installation of +10° / -10° each tile and the weight has been reduced down to 6,4 kg (50x50cm tiles) and 11,4 kg (50x100 tiles). The on-board electronics include the latest generation of Novastar A5s receiver card and refresh rate up to 3.840 Hz.

Main Features

Single person installation, auto lock design, scratch protection and flip corner shield
Built in curve mechanics for +10° / -10° concave & convex
Refresh rate of 3.840 Hz

VIDEO

Driver chip type: ICN 2153
LED source: Nationstar SMD1921 black frame and white face
Pixel pitch: 4.8mm / 0.19''
Panel resolution: 104x208pixels
Module resolution: 52x52pixels
Luminous flux: 3.500nit
Contrast: 3.000:1
Grayscale: 14 bit
Refresh rate ≥: 3.840Hz
Drive Mode: 1/13 scan, constant current
Vertical viewing angle: 120°
Horizontal viewing angle: 140°
LED density: 43.264LED/sqm
Dead Pixel Ratio: <0,002
LED avg life span: 100.000

ELECTRICAL

Power input/output: IPKON Seetronic IN/OUT
Power supply: AC 110/230 V 50/60 Hz
Max power consumption (panel): 300W
Avg power consumption (panel): 100W
Max power consumption (sqm): 600W
Avg power consumption (sqm): 200W
Standby power consumption (pannello): 100W
Max rated current/panel:: AC 220 V / 1.36 A
Working temperature: -20°C / +50°C
Working humidity: 10~90 RH%

CONTROL

Receiving card type: A5S PLUS
Other controllers type: mapping, firmware copy, RCFGX restore, calibration chip on LDM (module flash)
Control protocol: Novastar
Signal input: RJ45
Signal output: RJ45

MECHANICS

Other specifics: curve configurations (mechanics on board), corner protection, bottom protection, auto-lock mechanics
Magnetic LED modules: not available
Module size (WxH): 250x250mm / 9.84''x9.84''
Panel size(WxHxD): 500×1000×64mm / 19.69''
Vertical hanging system: built-in aliscaf clamp support
Cooling: natural cooling of the peculiar chassis and to absence of fans
Connection: seamless locking system
Curvability: convex and concave -10° / +10°
Body: die-cast aluminium housing
Color: black
IP rating: IP65/IP54 (front and rear)
Panel weight: 11,4kg / 25.13lbs
Weight per square meter: 22,8kg / 50.27lbs
Hanging Panel Quantity ≤: 10 for hanging and 6 for stacking
Compliant Standard: CE, UKCA
