Prolights

ÆtherBox LITE

Name: ÆtherBox LITE
Brand: Prolights
SKU: AETHERBOXLITE
Price: 600 EUR
Availability: InStock

1 Universe CRMX Wireless Transceiver

600.00€

(Including VAT 20%)

SKU: AETHERBOXLITE

Category: Pendant, Controllers

Tag: prolights, audio visual store, control systems

TheAetherBox Lite is a versatile, single universe Wireless CRMX Transceiver, offering compatibility with both Lumen Radio CRMX and Wireless DMX G3 and G4S protocols.

This compact unit provides flexible power and signal processing options via chassis connectors or terminal blocks. Its design allows for track mounting, enabling the streaming of signals on tracks equipped with a data bus option.

The AetherBox Lite is an effective solution for small and medium-sized live events or installations, delivering reliable wireless control in various settings.

Main Features

Single Univers Wireless CRMX Transceiver unit
Power IN and DMX In/Out through chassis mount connectors and terminal blocks
Either LumenRadio CRMX and Wireless DMX G3 and G4S transmission option

Important Links

Aetherboxlite_A4_DATASHEET_(EN)
Aetherboxlite_TENDER_SPECIFICATION

BODY

Hardware on-board: see available accessories
Body: sturdy policarbonate body
Body colour: black

CONTROL

Protocols: DMX512, RDM, CRMX + WDMX, Bluetooth
Wireless Control: included, LumenRadio TimoTwo DMX/RDM compatible with both CRMX, CRMX2 (Lumen Radio) and W-DMX (Wireless DMX), Bluetooth capable
RDM: RDM for remote monitoring and settings
Firmware upgrade: via DMX with UPBOXPRO/UPBOX1 (USB-DMX interface not included)
Other: 3 control buttons and status LEDs on-board
Other: transmission range up to 100 meters in open field

ELECTRONICS

Mains power supply: 100-240V - 50/60Hz
Max power consumption: 5W
Power factor: > 0,95

ELECTRICAL

Operating Temperature: -10° ~ +45°
IP rating: 20
Suspension and fixing: track-adapter option (track not included), for fixing in suspension
Signal connection: screw terminal block, Amphenol XLR 5p IN/OUT connectors
Power connection: screw terminal block, Seetronic powerCON TRUE IN
Dimensions (WxHxD): 140x60x100mm / 5.51''x2.36''x3.94''
Weight: 0,4kg / 0.88lbs

PHYSICAL

Operating Temperature: -10° ~ +45°
IP rating: 20
Suspension and fixing: track-adapter option (track not included), for fixing in suspension
Signal connection: screw terminal block, Amphenol XLR 5p IN/OUT connectors
Power connection: screw terminal block, Seetronic powerCON TRUE IN
Dimensions (WxHxD): 140x60x100mm / 5.51''x2.36''x3.94''
Weight: 0,4kg / 0.88lbs

CERTIFICATIONS / APPROVALS
